AS-1/20 is an S-band RF electron linear accelerator tube developed by Elekom, which adopts an on axis coupling accelerating structure. It has the advantages of compact structure, high dose rate and stable performance, which can be widely used in industrial detection and security inspection.
AS-1/20 | |||
Electron Beam Energy（MeV） | 1 | Pulse Width（μs） | 2.5-4.2 |
Dose Rate（cGy/min·m） | ≥20 | Duty Cycle（‰） | 1 |
Dose Rate Instability（％） | ≤1 | Ion Pump Voltage（kV） | 3.5-4.5 |
Operation Frequency（MHz） | 2998±1 | Cooling Water Temperature（℃） | 25-40 |
E-gun Voltage（kV） | 8-22 | Filament Current（A） | 2.2±0.2 |
Focal Spot Size（mm） | ≤1.0/1.5 | Heating Time Of Filament（min） | 3 |
Overall Length（mm） | ≤205 | Reserved Target Current Measuring Interface | Optional |
Magnetron Power（MW） | 2-2.6 | RF Window Flange | FAP 32（TYP） |
Input Power Of Accelerating Tube（MW） | ≥2 | Mounting Flange | Optional |
